SR03 Amber Laser Safety Barrier
Shieldrays SR03 laser barrier, made of Mitsubishi VH001 optical acrylic, 5mm thick, covers 315-535nm (OD5+) & 800-1100nm (OD5+) for fiber, blue, UV & green lasers. VLT 14% for enhanced light shielding, LIDT≤8 W/cm². Amber color, density 1.19kg/dm³. Max 1360×1050mm, custom sizes. Reliable safety for multi-wavelength laser environments.
Product Gallery
Description
SR03 uses Mitsubishi VH001 optical-grade acrylic and advanced absorption technology, delivering OD5+ protection at both 315-535nm and 800-1100nm bands, covering fiber (1064nm), blue (445nm), UV and green lasers. 14% VLT effectively attenuates ambient light for enhanced comfort and safety. 5mm thickness offers impact resistance, LIDT≤8 W/cm² withstands moderate-to-high power exposure. Amber color provides excellent filtering. Standard 1360×1050mm, custom sizes available.
Features
- • Broadband dual protection: 315-535nm & 800-1100nm, OD5+ for both
- • Low VLT 14% for enhanced light shielding & ambient light reduction
- • High damage threshold: LIDT≤8 W/cm²
- • Premium optical acrylic: Mitsubishi VH001, 5mm thick, impact & age resistant
- • Amber color with excellent filtering performance
- • Density 1.19kg/dm³, lightweight yet sturdy
- • CE certified for quality & safe
- • Large format: up to 1360×1050mm, custom sizes available
- • Versatile: compatible with fiber, blue, UV & green lasers
Specifications
- Model
- SR03
- Material
- Acrylic (Mitsubishi VH001)
- Thickness
- 5mm
- Protection Wavelength01 & OD Value
- 315-535nm OD5+
- Protection Wavelength02 & OD Value
- 800-1100nm, OD5+
- VLT
- 14%
- LIDT
- ≤8 W/cm²
- Color
- Amber
- Density
- 1.19kg/dm³
- Max size
- 1360×1050mm
- Custom
- Yes
- Lasers
- Fiber (1064nm), Blue (445nm), UV, Green
- Applications
- viewing windows, lab partitions, medical
- Cert
- CE
- Mounting
- bolts/clamps/custom.
Need certificates, pricing, or custom dimensions?
Send us your wavelength, OD requirement, dimensions, drawings, or application scenario.
